11.11 o: Keypad-Related Settings
262 YASKAWA SIEPYEULA5001C LA500 Technical Manual
11.11 o: Keypad-Related Settings
◆ o1: Keypad Display
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o1-01
(0500)
RUN
User Monitor Selection
Sets the U monitor for the Drive Mode. This parameter is only available with an LED
keypad.
106
(104 - 830)
348
o1-02
(0501)
RUN
Expert
Monitor Selection at
Power-up
Sets the monitor item that the keypad screen shows after you energize the drive. Refer
to “U: Monitors” for information about the monitor items that the keypad screen can
show. This parameter is only available with an LED keypad.
1 : Frequency Reference (U1-01)
2 : Direction
3 : Output Frequency (U1-02)
4 : Output Current (U1-03)
5 : User Monitor (o1-01)
1
(1 - 5)
348
o1-03
(0502)
Keypad Display Unit
Selection
Sets the display units for the frequency reference and output frequency.
0 : 0.01 Hz units
1 : 0.01% units
2 : Revolutions Per Minute (RPM)
3 : User Units
0
(0 - 3)
348
o1-10
(0520)
Expert
User Units Maximum
Value
Sets the value that the drive shows as the maximum output frequency.
Determined by o1-03
(1 - 60000)
349
o1-11
(0521)
Expert
User Units Decimal
Position
Sets the number of decimal places for frequency reference and monitor values.
0 : No Decimal Places (XXXXX)
1 : One Decimal Places (XXXX.X)
2 : Two Decimal Places (XXX.XX)
3 : Three Decimal Places (XX.XXX)
Determined by o1-03
(0 - 3)
349
o1-24 to o1-29:
(11AD - 11B2)
RUN
Custom Monitor 1 to 6
Sets a maximum of 6 monitors as user monitors. This parameter is only available when
using an LCD keypad.
o1-24: 101
o1-25: 102
o1-26: 103
o1-27 to o1-29: 0
(0, 101 - 999)
349
◆ o2: Keypad Operation
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o2-01
(0505)
Expert
LO/RE Key Function
Selection
Sets the function that lets you use to switch between LOCAL and REMOTE
Modes.
0 : Disabled
1 : Enabled
0
(0, 1)
350
o2-02
(0506)
Expert
STOP Key Function
Selection
Sets the function to use on the keypad to stop the drive when the Run command
source for the drive is REMOTE (external) and not assigned to the keypad.
0 : Disabled
1 : Enabled
0
(0, 1)
350
o2-03
(0507)
Expert
User Parameter Default
Value
Sets the function to keep the settings of changed parameters as user parameter defaults
to use during initialization.
0 : No change
1 : Set defaults
2 : Clear all
0
(0 - 2)
350
o2-04
(0508)
Expert
Drive Model (KVA)
Selection
Sets the Drive Model code. Set this parameter after replacing the control board.
Determined by the drive
(-)
351
