12.5 E: Motor Parameters
YASKAWA SIEPYEULA5001C LA500 Technical Manual 299
12.5 E: Motor Parameters
E parameters cover drive input voltage, V/f pattern, and motor parameters.
◆ E1: V/f Pattern for Motor 1
E1 parameters set the drive input voltage and motor V/f characteristics. To switch drive operation from one motor
to another motor, set the V/f characteristics for motor 1.
■ E1-01: Input AC Supply Voltage
No.
(Hex.)
Name Description
Default
(Range)
E1-01
(0300)
Input AC Supply Voltage
Sets the drive input voltage.
400 V: 400 V
(400 V Class: 310 - 510 V)
NOTICE: Damage to Equipment. Set E1-01 [Input AC Supply Voltage] to align with the drive input voltage (not motor voltage). If
this parameter is incorrect, the protective functions of the drive will not operate correctly and it can cause damage to the drive.
Values Related to the Drive Input Voltage
The value set in E1-01 is the base value that the drive uses for the motor protective functions in Table 12.3. With a
400 V class drive, the detection level changes for some motor protective functions.
Table 12.3 Values Related to the Drive Input Voltage
Voltage E1-01 Setting
Approximate Values
ov Detection Level
BTR Operation Level
(rr Detection Level)
*1
L2-05
[Undervoltage Detection Lvl
(Uv1)]
400 V class
Setting value ≥ 400 V 820 V 788 V 380 V
Setting value < 400 V 820 V 788 V 350 V
*1 This is the protection function enabled in drives with built-in braking transistors. These values show the level that will trigger the
built-in braking transistor. Refer to “YASKAWA AC Drive 72060001 Series Option Braking Unit and Braking Resistor Unit
Installation Manual (TOBPC72060001)” for more information.
■ E1-04: Maximum Output Frequency
No.
(Hex.)
Name Description
Default
(Range)
E1-04
(0303)
Maximum Output
Frequency
Sets the maximum output frequency for the V/f pattern.
Determined by A1-02
(10.0 - 120.0 Hz)
■ E1-05: Maximum Output Voltage
No.
(Hex.)
Name Description
Default
(Range)
E1-05
(0304)
Maximum Output Voltage
Sets the maximum output voltage for the V/f pattern.
400 V Class: 380.0 V
(400 V Class: 0.0 - 510.0
V)
■ E1-06: Base Frequency
No.
(Hex.)
Name Description
Default
(Range)
E1-06
(0305)
Base Frequency
Sets the base frequency for the V/f pattern.
Determined by A1-02
(0.0 - 120.0 Hz)
■ E1-07: Middle Output Frequency
No.
(Hex.)
Name Description
Default
(Range)
E1-07
(0306)
Middle Output Frequency
Sets a middle output frequency for the V/f pattern.
Determined by A1-02
(0.0 - 120.0 Hz)
V/f
OLV
V/f
OLV
V/f
OLV
V/f
OLV
V/f
OLV
