11.6 d: Reference Settings
244 YASKAWA SIEPYEULA5001C LA500 Technical Manual
11.6 d: Reference Settings
◆ d1: Speed Reference
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d1-01
(0280)
RUN
Speed Reference 1
Sets the Speed reference in the units from o1-03 [Frequency Display Unit Selection].
0.00 Hz
(0.00 - 120.00 Hz)
296
d1-02
(0281)
RUN
Speed Reference 2
Sets the speed reference in the units from o1-03 [Frequency Display Unit Selection].
0.00 Hz
(0.00 - 120.00 Hz)
296
d1-03
(0282)
RUN
Speed Reference 3
Sets the Speed reference in the units from o1-03 [Frequency Display Unit Selection].
0.00 Hz
(0.00 - 120.00 Hz)
296
d1-04
(0283)
RUN
Speed Reference 4
Sets the Speed reference in the units from o1-03 [Frequency Display Unit Selection].
0.00 Hz
(0.00 - 120.00 Hz)
296
d1-05
(0284)
RUN
Speed Reference 5
Sets the Speed reference in the units from o1-03 [Frequency Display Unit Selection].
0.00 Hz
(0.00 - 120.00 Hz)
296
d1-06
(0285)
RUN
Speed Reference 6
Sets the Speed reference in the units from o1-03 [Frequency Display Unit Selection].
0.00 Hz
(0.00 - 120.00 Hz)
296
d1-07
(0286)
RUN
Speed Reference 7
Sets the Speed reference in the units from o1-03 [Frequency Display Unit Selection].
0.00 Hz
(0.00 - 120.00 Hz)
297
d1-08
(0287)
RUN
Speed Reference 8
Sets the Speed reference in the units from o1-03 [Frequency Display Unit Selection].
0.00 Hz
(0.00 - 120.00 Hz)
297
d1-18
(02C0)
Spd Ref Sel Mode
Sets the priority of the speed reference digital inputs.
If d1-18 = 0, multi-speed references d1-01 to d1-08 are used.
If d1-18 = 1, values from parameters d1-19 to d1-23 have priority.
0 : Use Multi-Speed references d1-01 to d1-08
1 : High speed reference has priority
2 : Leveling speed reference has priority
1
(0 - 2)
297
d1-19
(02C1)
RUN
Nominal Speed
Sets the speed reference when multi-function input “Nominal Speed” is on.
50.00 Hz
(0.00 - 120.00 Hz)
297
d1-20
(02C2)
RUN
Intermed Speed 1
Sets the speed reference when intermediate speed 1 is selected by digital inputs.
0.00 Hz
(0.00 - 120.00 Hz)
297
d1-21
(02C3)
RUN
Intermed Speed 2
Sets the speed reference when intermediate speed 2 is selected by digital inputs.
0.00 Hz
(0.00 - 120.00 Hz)
297
d1-22
(02C4)
RUN
Intermed Speed 3
Sets the speed reference when intermediate speed 3 is selected by digital inputs.
0.00 Hz
(0.00 - 120.00 Hz)
298
d1-23
(02C5)
RUN
Releveling Speed
Sets the speed reference when releveling speed is selected by digital inputs.
0.00 Hz
(0.00 - 120.00 Hz)
298
d1-24
(02C6)
RUN
Inspect Oper Spd
Sets the speed reference when inspection speed is selected by digital inputs.
30.00 Hz
(0.00 - 120.00 Hz)
298
d1-25
(02C7)
RUN
Rescue Oper Spd
Sets the speed reference when rescue speed is selected by digital inputs.
5.00 Hz
(0.00 - 15.00 Hz)
298
d1-26
(02C8)
RUN
Leveling Speed
Sets the speed reference when leveling speed is selected by digital inputs.
4.00 Hz
(0.00 - 120.00 Hz)
298
