12.10 S: Elevator Parameters
366 YASKAWA SIEPYEULA5001C LA500 Technical Manual
■ S6-02: Starting Current Error (SE2) Detection Delay Time
No.
(Hex.)
Name Description
Default
(Range)
S6-02
(06B4)
Starting Current Error
(SE2) Detection Delay
Time
Sets a delay time for starting current error (SE2). SE2 is detected when the drive output current is
below 25% after the Up/Down command has been entered and the brake release time and the time
set to S6-02 have both passed. The brake control command will not be issued (brake stays
applied).
200 ms
(0.00 - [S1-04 - S1-06] ms)
■ S6-04: Output Current Error (SE3) Detection Delay Time
No.
(Hex.)
Name Description
Default
(Range)
S6-04
(06B6)
Output Current Error (SE3)
Detection Delay Time
Sets a delay time for detecting an output current fault (SE3). SE3 is detected when the drive
output current drops below 25% after the brake has released.
200 ms
(0 - 5000 ms)
■ S6-05: Brake Response Error (SE4) Detection Time
No.
(Hex.)
Name Description
Default
(Range)
S6-05
(06B7)
Brake Response Error
(SE4) Detection Time
Sets a delay time for detecting a brake response error (SE4). SE4 is detected when an output
terminal set for “Brake release” (H2-xx = 50) and an input terminal set for “Brake feedback” (H1-
xx = 79) do match for the time set to S6- 05.
500 ms
(0 - 10000 ms)
■ S6-15: Speed Reference Loss Detection
No.
(Hex.)
Name Description
Default
(Range)
S6-15
(06BB)
Speed Reference Loss
Detection
Enables speed reference loss detection when D1-18 = 1 and H1-xx ≠ 53.
0
(0, 1)
0 : Disabled
1 : Enabled
■ S6-16: Restart after Baseblock Selection
No.
(Hex.)
Name Description
Default
(Range)
S6-16
(06BC)
Restart after Baseblock
Selection
Allows the drive to restart the motor after returning to normal operation from Baseblock state
(H1-xx = 8/9) or from Safe Torque-Off state (Safe Disable inputs H1 and H2 enabled) while the
Up/Down command is still active.
0
(0, 1)
V/f
OLV
V/f
OLV
V/f
OLV
V/f
OLV
V/f
OLV
