<6. PARAMETER DESCRIPTION>
6-11
IM 01E30D01-01EN
(8) Item H (Menu H): Display Setting items
Menu H contains setting items that are relevant to display on the display unit.
Item
Name
R/W
Data range
Units
Position
of decimal
point
Default value
(*): Indicated item
Description
Display unit
(BRAIN)
Display unit
/BRAIN
H00 Display Set
(DISP SET)
H10 Display Select1
(DISP SELECT1)
W Flow Rate(%)
Flow Rate
Flow Rate(mA)
Forward Total
Reverse Total
Dif Total
Flow Rate(%) Selectscontentoftherstline
for Display Mode. Linked with
B40.
H11 Display Select2
(DISP SELECT2)
W Off
Flow Rate(%)
Flow Rate
Flow Rate(mA)
Flow Rate(Bar)
Forward Total
Reverse Total
Dif Total
Adhesion Check
Communication
(*1)
Tag No
Long Tag No(Hi) (*2)
Long Tag No(Lo) (*2)
Off Selects content of the second
line for Display Mode. Linked
with B41.
(*1) Displays communication
type according to Output Signal
and Communication code:
●-D:BRAIN
●-E:HART5
●-J:HART5orHART7
(*2) Long tag No(Hi) and Long
Tag No (Lo) are only for HART
7.
H12 Display Select3
(DISP SELECT3)
W Same as H11
(Display Select2)
Off Selects content of the third line
for Display Mode. Linked with
B42.
H20 Display Cycle
(DISP CYCLE)
W 400ms
1s
2s
4s
8s
400ms Selects the display cycle.
H30 Language
(LANGUAGE)
W English
Japanese
French
German
Italian
Spanish
English Selects the language used by
the display unit. Linked with
B10.
H40 LCD Contrast
(LCD CONTRAST)
W 0 to 20 0 Factory setting
value
Selects the display contrast
H60 —
(SELF CHECK)
R Good
Error
Read Section 6.5 “Alarm
Functions”.
