(9) Item J (Menu J): Auxiliary Function Setting items
MenuJcontainssettingitemssuchastheowdirection,ratelimits,andlowcut.
Item
Name
R/W
Data range
Units
Position
of decimal
point
Default value
(*): Indicated item
Description
Display unit
(BRAIN)
Display unit
/BRAIN
J00 Aux
(AUX)
J10 4-20mA Low Cut
(4-20 LOW CUT)
W 0 to 20 % 0 3% Sets the range in vicinity of 0%
within which the current output
will be 4 mA.
J11 4-20mA Low Lmt
(4-20 LOW LMT)
W -1.25 to 100.00 % 2 -1.25% Sets the low limit for current
output
J12 4-20mA High Lmt
(4-20 HI LMT)
W 0.0 to 103.13 % 2 103.13% Sets the high limit for current
output
J15 Pls Special Mode
(PLS SPECIAL)
W Normal
Pulse Only
Normal Selects the pulse special mode
J20 Flow Direction
(FLOW DIRECT)
W Forward
Reverse
Forward Selectstheowdirection.
J21 Rate Limit
(RATE LIMIT)
W 0 to10 % 0 5% Sets the level to reduce output
uctuation.
J22 Dead Time
(DEAD TIME)
W 0 to 15 s 0 0s Sets the dead time to reduce
outputuctuation.When“0”
is set, rate limit function is not
available.
J23 Pulsing Flow
(PULSING FLOW)
W No
Yes
No Selectswhetherpulsingowis
to be supported.
J25 T/P Damp Select
(T/P DAMP SEL)
W Damping
No Damping
Damping Selectswhethertheow
rate value obtained through
damping calculation for total/
pulseortheinstantaneousow
rate value (no damping) for
total/pulse is to be used.
J30 Basic Frequency
(BASIC FREQ)
W Freq(1)
Freq(2)
Freq(1) Selects the basic frequency
J35 Memo 1
(MEMO 1)
W
ASCII 16 characters Memoeld
J36 Memo 2
(MEMO 2)
W
ASCII 16 characters Memoeld
J37 Memo 3
(MEMO 3)
W
ASCII 16 characters Memoeld
J40 MS Code 1
(MS CODE 1)
W
ASC II 16 characters Sets MS code 1
J41 MS Code 2
(MS CODE 2)
W
ASCII 16 characters Sets MS code 2
J42 MS Code 3
(MS CODE 3)
W
ASCII 16 characters Sets MS code 3
J43 MS Code 4
(MS CODE 4)
W
ASCII 16 characters Sets MS code 4
J44 MS Code 5
(MS CODE 5)
W
ASCII 16 characters Sets MS code 5
J45 MS Code 6
(MS CODE 6)
W
ASCII 16 characters Sets MS code 6
J50 Software Rev No
(SOFTWARE REV)
R — Software revision number
J60 —
(SELF CHECK)
R Good
Error
Read Section 6.5 “Alarm
Functions”.
