<6. PARAMETER DESCRIPTION>
6-13
IM 01E30D01-01EN
(10) Item K (Menu K): Diagnostic Function Setting items
Menu K contains items that are relevant to the diagnosis of insulation adhesion to the electrode.
Item
Name
R/W
Data range
Units
Position
of decimal
point
Default value
(*): Indicated item
Description
Display unit
(BRAIN)
Display unit
/BRAIN
K00 Diagnosis
(DIAGNOSIS)
K10 Adhesion Check
(ADHESION CHK)
W No Execution
Execution
No Execution Selects whether or not to
perform diagnosis of adhesion
to the electrode.
K11 Adh Status
(ADH STATUS)
R Level0
Level1
Level2
Level3
Level4
Level0 Displays the status of adhesion
level
K12 Adh Measure Value
(ADH MEAS VAL)
R — M ohm 2 0.00M ohm Displays the resistance value
for adhesion to the electrode.
K13 Adhesion Level1
(ADH LEVEL1)
W 0.00 to 100.00 M ohm 2 0.35 Sets the resistance value
for adhesion Level 1 to the
electorode.
K14 Adhesion Level2
(ADH LEVEL2)
W 0.00 to 100.00 M ohm 2 0.40 Sets the resistance value
for adhesion Level 2 to the
electorode.
K15 Adhesion Level3
(ADH LEVEL3)
W 0.00 to 100.00 M ohm 2 0.45 Sets the resistance value
for adhesion Level 3 to the
electorode.
K16 Adhesion Level4
(ADH LEVEL4)
W 0.00 to 100.00 M ohm 2 0.60 Sets the resistance value
for adhesion Level 4 to the
electorode.
K17 Adh Chk Cyc
(ADH CHK CYC)
W 0.5 min
1 min
5 min
10 min
min 5 min Selects execution time of
adhesion check
K19 Empty Check
(EMPTY CHECK)
W No
Low
Middle
High
No Selects whether or not to
perform diagnosis of empty
pipe check.
K20 Empty Status
(EMPTY STATUS)
R Normal
Empty
Normal Displays status of empty pipe
K21 DC Voltage A
(DC VOLTAGE A)
R — V 2 Displays the voltage level at
electrode A
K22 DC Voltage B
(DC VOLTAGE B)
R — V 2 Displays the voltage level at
electrode B
K23 Empty Level
(EMPTY LEVEL)
W -1.5 to 1.5 V 1 -1.2V Sets the volatage level for
empty pipe detection at the
electrodes
K60 —
(SELF CHECK)
R Good
Error
Read Section 6.5 “Alarm
Functions”.
To Next Page
