(11) Item M (Menu M): Automatic Zero-Adjustment Function Setting items
Menu M contains items that are relevant to automatic zero adjustment.
Item
Name
R/W
Data range
Units
Position
of decimal
point
Default value
(*): Indicated item
Description
Display unit
(BRAIN)
Display unit
/BRAIN
M00 Adjustment
(ADJUSTMENT)
M10 Auto Zero Exe
(AUTOZEROEXE)
W No Execution
Execution
No Execution Selects whether or not
automatic zero adjustment is
carried out. Linked with B50.
M11 Autozero Time
(AUTOZ TIME)
W 1 to 900 s 0 450 s Sets execution time for
automatic zero adjustment
M12 Flow Zero(IEL)
(FL ZERO(IEL))
W -99.999 to 99.999 3 0.000 Displays the result of automatic
zero adjustment (excitation
current (Low))
M13 Flow Zero(IEM)
(FL ZERO(IEM))
W -99.999 to 99.999 3 0.000 Displays the result of automatic
zero adjustment (excitation
current (Middle))
M14 Flow Zero(IEH)
(FL ZERO(IEH))
W -99.999 to 99.999 3 0.000 Displays the result of automatic
zero adjustment (excitation
current (High))
M15 Flow Span Adjust
(FL SPAN ADJ)
W 0.4000 to 2.0000 4 1.0000 Setsadjustmentfactorofow
span
M20 Adjustment 4mA
(ADJUST 4mA)
W -10.00 to 10.00 % 2 0.00 % Sets adjustment for 4mA output
M21 Adjustment 20mA
(ADJUST 20mA)
W -10.00 to 10.00 % 2 0.00 % Sets adjustment for 20mA
output
M60 —
(SELF CHECK)
R Good
Error
Read Section 6.5 “Alarm
Functions”.
(12) Item N (Menu N): Loop Test Setting items
Menu N contains items that are relevant to the execution of loop testing.
Item
Name
R/W
Data range
Units
Position
of decimal
point
Default value
(*): Indicated item
Description
Display unit
(BRAIN)
Display unit
/BRAIN
N00 Test
(TEST)
N10 Test Mode
(TEST MODE)
W Normal
Test
Normal Selects whether mode will be
set to “Normal” or “Test”.
N11 Test Output Value
(TEST OUT VAL)
W -1 to 103 % 0 0% Sets the test output value.
N12 Test DO
(TEST DO)
W Open(Off)
Closed(On)
Pulse
Open(Off) Selects the test condition for
DO terminal.
N15 Test Time
(TEST TIME)
W 10min
30min
60min
3h
6h
12h
30min Select the holding time of the
test mode
N20 Test Iex
(TESTIEX)
W Normal
Test (Iex OFF)
Normal Selects the test of excitation
current
N30 Flow Tube
(FLOW TUBE)
W Detector
Calibrator
Detector Selects type of operating
owtube
N40 Average Execution
(AVGEXEC)
W Stop
Start
Stop Selects whether the execution
for measurement of averaged
owrateisoccurrence
N41 Average Timer
(AVG TIMER)
W 1 to 600 s 0 30 s Sets totalization time for
measurement of averaged
owrate
N42 Average Flow
(AVG FLOW)
R -999999 to 999999 C40/C41 0 to 5 0.00000 m/s Displaystheaveragedowrate
N60 —
(SELF CHECK)
R Good
Error
Read Section 6.5 “Alarm
Functions”.
