<6. PARAMETER DESCRIPTION>
6-35
IM 01E30D01-01EN
[J30: Basic Frequency] Selection of the basic
frequency
This parameter is changed from default setting as
“Freq(1)”to“Freq(2)”ifthemagneticowmeter
occurred the error caused by installation of a next
magneticowmeterclosely.
[J35: Memo 1] Setting of memo 1
[J36: Memo 2] Setting of memo 2
[J37: Memo 3] Setting of memo 3
These parameters are used with the memo
function, and up to 16 characters can be set for
each.
[J40: MS CODE 1] Setting of MS code 1
[J41: MS CODE 2] Setting of MS code 2
[J42: MS CODE 3] Setting of MS code 3
[J43: MS CODE 4] Setting of MS code 4
[J44: MS CODE 5] Setting of MS code 5
[J45: MS CODE 6] Setting of MS code 6
The MS codes are set.
[J50: Software Rev No] Display of software revision
This parameter is used to display the software’s
revision number.
(9) Menu K: Diagnostic Function Setting items
Menu K contains items that are relevant to the
diagnosis of insulation adhesion to the electrode
and so on.
[K10: Adhesion Check] Execution of adhesion
diagnostic function
This parameter is used to execute the adhesion
diagnostic function. If “Execution” is selected, this
function will be started. “Now Adhesion Check
Executing” is displayed while the adhesion
diagnostic function is being carried out. The result
ofadhesiondiagnosiscanbeconrmedbyusing
K12. (Read Chapter 11.)
Setting Function
No Execution Adhesion diagnosis is not executed.
Execution Adhesion diagnosis is started.
The current output becomes 4 mA during this
execution (approximately 5 minutes).
NOTE
Adhesion Diagnostic Function
• Thisfunctiondiagnoseadhesionusing
electrode resistance values.
• Theresultofadhesiondiagnosisisdisplayed
at K12:Adh Measure Value.
• When“Adhesioncheck”hasbeensetfor
B41/H11:DisplaySelect2 or B42/H12:
Display Select 3, the diagnose adhesion
is indicated on the display unit using four
different levels.
• IfthejudgmentvalueforLevel3is
exceeded, a warning is displayed; and if
the value for Level 4 is exceeded, an alarm
or warning is displayed depending on the
setting condition at G29.
• Availableconductivityforthisfunctionis
limited to 10 µS/cm.
Make sure to use the adhesion diagnostic
function with the greater conductivity than
the above mentioned value.
