YOKOGAWA ADMAG AXR User Manual

<6. PARAMETER DESCRIPTION>
6-39
IM 01E30D01-01EN
[N15: Test Time] Selection of the holding time of
test mode
This parameter is used to select the holding time of
test mode from the last operation in test mode.
Setting Function
10min The holding time is 10min
30min The holding time is 30min
60min The holding time is 60min
3h The holding time is 3h
6h The holding time is 6h
12h The holding time is 12h
[N20: Test Iex] Selection of the test for excitation
current
This parameter is used to select a test for excitation
current.Theexcitationcurrentvalueisforciblyxed
at zero during this test. Setting is possible when
“Test” has been selected for N10: Test Mode.
Setting Function
Normal Normal operation
Test
(Iex OFF)
Testing is started.
Theexcitationcurrentvalueisforciblyxedat
zero.
IMPORTANT
1) The default setting is “Normal.”
Use the instrument with this default setting.
2) When the setting is “Test (lex OFF),” the
outputisxedto0%.
Inthecaseofsetting“Test(lexOFF),”rst
change the control loop to the manual mode,
and then set this parameter.
3) “Normal” will be restored when the power is
turned off or when the time set at N15: Test
Time have elapsed since entry to “Test (lex
OFF).”
[N30: Flow Tube]Selectionofoperatingowtube
type
This parameter is used to select the type of
operatingowtubewhichisconnectedtothe
converter. The parameter would be selected
as “Detector” for typical use. This parameter is
selected as “Calibrator” when the converter is
connected to the calibrator.
[N40: Average Execution] Selection of execution
formeasurementofaveragedowrate
This parameter is used to select whether the
executionformeasurementofaveragedowrateis
occurrence in a constant time.
Setting Function
Stop Stopping the execution of measurement for
averagedowrate.
Start Starting the execution of measurement for
averagedowrate.Thetotalizationisstartedin
a time, which was set at N41: Average Timer
using the value being set at B20(C11): Flow
Damping when this function is started. This
totalization is calculated at the result of instant
owrateforatimewherewassetatN41.
[N41: Average Timer] Setting of totalization time
formeasurementofaveragedowrate
This parameter is used to set the totalization time
foraveragedowratemeasurement.
[N42: Average Flow] Display of the averaged
owrate
This parameter is used to display the averaged
owrateforatimewhenissetatN41 as totalizatoin
time after selecting the “Start” at N40.
(12) Menu P: Parameter Protection items
Menu P contains items that are relevant to write
protection and passwords.
[P10: Key Code] Parameter of the display
restriction
This parameter restricts access to the Service
Mode.
NOTE
Write Protect function
■ TheparametersP20 through P23 are
set when using the write protect function.
Specically,thisfunctionrespondstoa
hardware switch or the setting of a software
password, and it protects parameters from
being overwritten.
■ Ifthehardwareswitchissetto“Protect”,it
will not be possible to overwrite parameters;
furthermore, this condition will be maintained
until the switch is set to “Enable.”
■ Formoredetailsregardinghardwareswitch
settings, read Subsection 11.3.2.
