9 - 4 DS457 Fixed Mount Imager Integration Guide
Serial Host Parameters (continued)
Selecting ICL, Fujitsu, Wincor-Nixdorf Mode A, Wincor-Nixdorf Mode B, OPOS/JPOS, Olivetti, Omron, or
Common Use Terminal Equipment (CUTE-LP/LG bar code readers) enables the transmission of code ID
characters listed in Table 9-3. These code ID characters are not programmable and are separate from the
Transmit Code ID feature. Do not enable the Transmit Code ID feature for these terminals.
Table 9-3 Terminal Specific Code ID Characters
Code Type ICL Fujitsu
Wincor-
Nixdorf
Mode A
Wincor-Nixdorf
Mode B/
OPOS/JPOS
Olivetti Omron CUTE
UPC-A AAA A A A A
UPC-E EEC C C E None
EAN-8/JAN-8 FF FF B B B FF None
EAN-13/JAN-13 FFA A A F A
Bookland EAN FFA A A F None
Code 39 C <len> None M M M <len> C <len> 3
Code 39 Full ASCII None None M M None None 3
Trioptic None None None None None None None
Code 32 None None None None None None None
Codabar N <len> None N N N <len> N <len> None
Code 128 L <len> None K K K <len> L <len> 5
GS1-128 L <len> None P P P <len> L <len> 5
Code 93 None None L L L <len> None None
I 2 of 5 I <len> None I I I <len> I <len> 1
D 2 of 5 H <len> None H H H <len> H <len> 2
MSI None None O O O <len> None None
Code 11 None None None None None None None
IATA H<len> None H H H<len> H<len> 2
GS1 Databar
Variants
None None E E None None None
PDF417 None None Q Q None None 6
MicroPDF417 None None S S None None 6
Data Matrix None None R R None None 4
Maxicode None None T T None None None
QR Codes None None U U None None 7
Aztec/Aztec Rune None None V V None None 8

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
