Zebra DS457 User Manual

Symbologies 12 - 3
Transmit UPC-A Check Digit 40 28h Enable 12-17
Transmit UPC-E Check Digit 41 29h Enable 12-17
Transmit UPC-E1 Check Digit 42 2Ah Enable 12-18
UPC-A Preamble 34 22h System Character 12-19
UPC-E Preamble 35 23h System Character 12-20
UPC-E1 Preamble 36 24h System Character 12-21
Convert UPC-E to A 37 25h Disable 12-22
Convert UPC-E1 to A 38 26h Disable 12-22
EAN-8/JAN-8 Extend 39 27h Disable 12-23
Bookland ISBN Format 576 F1h 40h ISBN-10 12-24
UCC Coupon Extended Code 85 55h Disable 12-25
Coupon Report 730 F1h DAh New Coupon
Format
12-26
ISSN EAN 617 F1h 69h Disable 12-27
Code 128
Code 128 8 08h Enable 12-28
Set Length(s) for Code 128 209, 210 D1h, D2h Any Length 12-28
GS1-128 (formerly UCC/EAN-128) 14 0Eh Enable 12-30
ISBT 128 84 54h Enable 12-30
ISBT Concatenation 577 F1h 41h Disable 12-31
Check ISBT Table 578 F1h 42h Enable 12-32
ISBT Concatenation Redundancy 223 DFh 10 12-32
Code 128 Security Level 751 F3h EFh Security Level 1 12-33
Code 39
Code 39 0 00h Enable 12-34
Trioptic Code 39 13 0Dh Disable 12-34
Convert Code 39 to Code 32
(Italian Pharmacy Code)
86 56h Disable 12-35
Code 32 Prefix 231 E7h Disable 12-35
Set Length(s) for Code 39 18, 19 12h, 13h 2 to 55 12-36
Code 39 Check Digit Verification 48 30h Disable 12-37
Table 12-1 Symbology Default Table (Continued)
Parameter
Parameter
Number
SSI
Number
Default
Page
Number

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
