Zebra DS457 User Manual

12 - 4 DS457 Fixed Mount Imager Integration Guide
Transmit Code 39 Check Digit 43 2Bh Disable 12-48
Code 39 Full ASCII Conversion 17 11h Disable 12-38
Buffer Code 39 113 71h Disable 12-39
Code 39 Security Level 750 F3h EEh Security Level 1 12-42
Code 93
Code 93 9 09h Disable 12-43
Set Length(s) for Code 93 26, 27 1Ah, 1Bh 4 to 55 12-43
Code 11
Code 11 10 0Ah Disable 12-45
Set Lengths for Code 11 28, 29 1Ch, 1Dh 4 to 55 12-45
Code 11 Check Digit Verification 52 34h Disable 12-47
Transmit Code 11 Check Digit(s) 47 2Fh Disable 12-48
Interleaved 2 of 5 (ITF)
Interleaved 2 of 5 (ITF) 6 06h Enable 12-48
Set Lengths for I 2 of 5 22, 23 16h, 17h Range 6 - 55 12-49
I 2 of 5 Check Digit Verification 49 31h Disable 12-50
Transmit I 2 of 5 Check Digit 44 2Ch Disable 12-51
Convert I 2 of 5 to EAN 13 82 52h Disable 12-51
I 2 of 5 Security Level 1121 Security Level 1 12-52
Discrete 2 of 5 (DTF)
Discrete 2 of 5 5 05h Disable 12-53
Set Length(s) for D 2 of 5 20, 21 14h 15h 12 12-53
Codabar (NW - 7)
Codabar 7 07h Disable 12-55
Set Lengths for Codabar 24, 25 18h, 19h 5 to 55 12-55
CLSI Editing 54 36h Disable 12-57
NOTIS Editing 55 37h Disable 12-57
Codabar Upper or Lower Case Start/Stop
Characters Transmission
855 F2h 57h Upper Case 12-58
Table 12-1 Symbology Default Table (Continued)
Parameter
Parameter
Number
SSI
Number
Default
Page
Number

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
