A - 6 DS457 Fixed Mount Imager Integration Guide
USB FN1 Substitution N/A N/A Disable
10-11
Function Key Mapping N/A N/A Disable
10-11
Simulated Caps Lock N/A N/A Disable
10-12
Convert Case N/A N/A None
10-13
USB Static CDC N/A N/A Enable
10-13
USB Ignore Beep Directive N/A N/A Honor
10-14
USB Ignore Type Directive N/A N/A Honor
10-14
USB Polling Interval N/A N/A 3 msec
10-15
Fast HID Keyboard N/A N/A Enable
10-17
IBM Specification Level N/A N/A Version 0 (Original)
10-17
OCR Programming Parameters
OCR-A 680 F1h A8h Disable
11-3
OCR-A Variant 684 F1h ACh Full ASCII
11-3
OCR-B 681 F1h A9h Disable
11-5
OCR-B Variant 685 F1h ADh Full ASCII
11-6
MICR E13B 682 F1h AAh Disable
11-9
US Currency 683 F1h ABh Disable
11-10
OCR Orientation 687 F1h AFh
0
o
11-10
OCR Lines 691 F1h B3h 1
11-12
OCR Min Char 689 F1h B1h 3
11-13
OCR Max Char 690 F1h B2h 100
11-13
OCR Security Level 554 F1h 2Ah 80
11-13
OCR Subset 686 F1h AEh Selected font variant
11-14
OCR Quiet Zone 695 F1h B7h 50
11-14
OCR Bright Illumination 701 F1h BDh Disable
11-15
OCR Template 547 F1h 23h 54R
11-16
OCR Check Digit Modulus 688 F1h B0h 1
11-25
OCR Check Digit Multiplier 700 F1h BCh 121212121212
11-26
OCR Check Digit Validation 694 F1h B6h None
11-27
Table A-1
Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.
