Zebra DS457 User Manual

A - 8 DS457 Fixed Mount Imager Integration Guide
Code 128
Code 128 8 08h Enable 12-28
Set Length(s) for Code 128 209, 210 D1h D2h Any Length 12-28
GS1-128 (UCC/EAN-128) 14 0Eh Enable 12-30
ISBT 128 84 54h Enable 12-30
ISBT Concatenation 577 F1h 41h Disable 12-31
Check ISBT Table 578 F1h 42h Enable 12-32
ISBT Concatenation Redundancy 223 DFh 10 12-32
Code 128 Security Level 751 F3h EFh Security Level 1 12-33
Code 39
Code 39 0 00h Enable 12-34
Trioptic Code 39 13 0Dh Disable 12-34
Convert Code 39 to Code 32
(Italian Pharmacy Code)
86 56h Disable 12-35
Code 32 Prefix 231 E7h Disable 12-35
Set Length(s) for Code 39 18, 19 12h 13h 2 to 55 12-36
Code 39 Check Digit Verification 48 30h Disable 12-37
Transmit Code 39 Check Digit 43 2Bh Disable 12-38
Code 39 Full ASCII Conversion 17 11h Disable 12-38
Buffer Code 39 113 71h Disable 12-39
Code 39 Security Level 750 F3h EEh Security Level 1 12-42
Code 93
Code 93 9 09h Disable 12-43
Set Length(s) for Code 93 26, 27 1Ah 1Bh 4 to 55 12-43
Code 11
Code 11 10 0Ah Disable 12-45
Set Lengths for Code 11 28, 29 1Ch 1Dh 4 to 55 12-45
Code 11 Check Digit Verification 52 34h Disable 12-47
Transmit Code 11 Check Digit(s) 47 2Fh Disable 12-48
Table A-1 Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
