Zebra DS457 User Manual

Standard Default Parameters A - 9
Interleaved 2 of 5 (ITF)
Interleaved 2 of 5 (ITF) 6 06h Enable 12-48
Set Lengths for I 2 of 5 22, 23 16h 17h Range 6 - 55 12-49
I 2 of 5 Check Digit Verification 49 31h Disable 12-50
Transmit I 2 of 5 Check Digit 44 2Ch Disable 12-51
Convert I 2 of 5 to EAN 13 82 52h Disable 12-51
I 2 of 5 Security Level 1121 Security Level 1 12-52
Discrete 2 of 5 (DTF)
Discrete 2 of 5 5 05h Disable 12-53
Set Length(s) for D 2 of 5 20, 21 14h 15h 12 12-53
Codabar (NW - 7)
Codabar 7 07h Disable 12-55
Set Lengths for Codabar 24, 25 18h 19h 5 to 55 12-55
CLSI Editing 54 36h Disable 12-57
NOTIS Editing 55 37h Disable 12-57
Codabar Upper or Lower Case
Start/Stop Characters Transmission
855 F2h 57h Upper Case 12-58
MSI
MSI 11 0Bh Disable 12-59
Set Length(s) for MSI 30, 31 1Eh 1Fh 4 to 55 12-59
MSI Check Digits 50 32h One 12-61
Transmit MSI Check Digit 46 2Eh Disable 12-62
MSI Check Digit Algorithm 51 33h Mod 10/Mod 10 12-62
Chinese 2 of 5
Chinese 2 of 5 408 F0h 98h Disable 12-63
Matrix 2 of 5
Matrix 2 of 5 618 F1h 6Ah Disable 12-63
Matrix 2 of 5 Lengths 619, 620 F1h 6Bh
F1h 6Ch
1 Length: 14 12-64
Matrix 2 of 5 Check Digit 622 F1h 6Eh Disable 12-65
Table A-1 Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
