A - 10 DS457 Fixed Mount Imager Integration Guide
Transmit Matrix 2 of 5 Check Digit 623 F1h 6Fh Disable 12-65
Korean 3 of 5
Korean 3 of 5 581 F1h 45h Disable 12-66
Inverse 1D 586 F1h 4Ah DS457-SR/HD/DL:
Regular
DS457-DP:
Inverse Autodetect
12-67
Postal Codes
US Postnet 89 59h Disable 12-68
US Planet 90 5Ah Disable 12-68
Transmit US Postal Check Digit 95 5Fh Enable 12-69
UK Postal 91 5Bh Disable 12-69
Transmit UK Postal Check Digit 96 60h Enable 12-70
Japan Postal 290 F0h 22h Disable 12-70
Australia Post 291 F0h 23h Disable 12-71
Australia Post Format 718 F1h CEh Autodiscriminate 12-72
Netherlands KIX Code 326 F0h 46h Disable 12-73
USPS 4CB/One Code/Intelligent Mail 592 F1h 50h Disable 12-74
UPU FICS Postal 611 F1h 63h Disable 12-74
GS1 DataBar (formerly RSS, Reduced Space Symbology)
GS1 DataBar (GS1 DataBar
Omnidirectional, GS1 DataBar
Truncated, GS1 DataBar Stacked,
GS1
DataBar Stacked Omnidirectional)
338 F0h 52h Enable 12-75
GS1 DataBar Limited 339 F0h 53h Enable 12-76
GS1 DataBar Limited Security Level 728 F1h D8h 3 12-77
GS1 DataBar Expanded (GS1 DataBar
Expanded, GS1 DataBar Expanded
Stacked)
340 F0h 54h Enable 12-78
Convert GS1 DataBar to UPC/EAN 397 F0h 8Dh Disable 12-78
Composite
Composite CC-C 341 F0h 55h Disable 12-79
Composite CC-A/B 342 F0h 56h Disable 12-79
Table A-1 Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
