Getting Started
23
12.
Align the keypad along the bottom ridge of the device, and then lay it flat.
13. Using a Torx T8 screwdriver with a large grip and a long shaft, secure the keypad to the device using
the two screws. Torque screws to 5.8 kgf-cm or 5.0 lbf-in.
14. Turn the device over so that the keypad latches are visible.
1 Keypad screws
1
