Zebra MC93 Series - Page 24

Getting Started
24
15.
Slide both the keypad latches toward the top of the device.
16. Using a Torx T8 screwdriver, replace the two keypad latch screws inside the battery slot and torque to
5.8 kgf-cm or 5.0 lbf-in.
17. Insert the battery.
18. Press and hold the Power key to power on the device.
1 Keypad latches
1 Keypad latch screws
1
1
