Zebra TC75 Integrator Guide

Settings 6 - 5
Figure 6-5 PIN Screen
Set Screen Unlock Using Password
1. Touch > .
2. Touch Security.
3. Touch Screen lock.
4. Touch Password.
5. Touch in the text field.
6. Enter a password (between 4 and 16 characters) then touch Next.
7. Re-enter the password and then touch Next.
8. Touch . The next time the device goes into suspend mode a PIN is required upon waking.

Zebra TC75 Specifications

General

Display Size	4.7 inches
Resolution	1280 x 720 pixels
Operating System	Android
Battery Capacity	4620 mAh
Cellular Connectivity	4G LTE
GPS	Yes
Humidity	5% to 95% non-condensing
Camera	8 MP rear camera
Wireless Connectivity	Wi-Fi 802.11 a/b/g/n
Ruggedness	MIL-STD-810G
Operating Temperature	-20° C to 50° C
Barcode Scanner	1D/2D imager
RAM	1 GB
Storage	8 GB
Expandable Storage	up to 32 GB microSD
Dimensions	6.3 x 3.3 x 1.1 inches
