2 - 36 TC75 Integrator Guide

11. Connect the output power plug into the power port on the 4-Slot Battery Charger.

Figure 2-42 Connect Adapter Power Cable

Removing the 4-Slot Battery Charger

1. Disconnect the output power plug from the 4-Slot Battery Charger.

2. At the back of the cup, press down on the release latch.

Figure 2-43 Press Release Latch

3. Slide the 4-Slot Battery Charger toward the front of the cradle.

4. Lift the 4-Slot off the cradle cup.
