Zebra TC75 Integrator Guide

2 - 26 TC75 Integrator Guide
Figure 2-29 Daisy-chaining 5-Slot Ethernet Cradles
4. Connect additional cradles as described in step 2 and 3.
Ethernet Settings
The following settings can be configured when using Ethernet communication:
• Proxy Settings
• Static IP.
Configuring Ethernet Proxy Settings
The TC75 includes Ethernet cradle drivers. After inserting the TC75, configure the Ethernet connection:
1. Touch > .
2. Touch Ethernet.
3. Place the TC75 into the Ethernet cradle slot.
4. Slide the switch to the ON position.
5. Touch .
6. Touch Advanced.
To Switch To Power Supply
To Power SupplyTo Next
Cradle

Zebra TC75 Specifications

General

Display Size	4.7 inches
Resolution	1280 x 720 pixels
Operating System	Android
Battery Capacity	4620 mAh
Cellular Connectivity	4G LTE
GPS	Yes
Humidity	5% to 95% non-condensing
Camera	8 MP rear camera
Wireless Connectivity	Wi-Fi 802.11 a/b/g/n
Ruggedness	MIL-STD-810G
Operating Temperature	-20° C to 50° C
Barcode Scanner	1D/2D imager
RAM	1 GB
Storage	8 GB
Expandable Storage	up to 32 GB microSD
Dimensions	6.3 x 3.3 x 1.1 inches
