2 - 24 TC75 Integrator Guide
5-Slot Ethernet Cradle
The 5-Slot Ethernet Cradle:
• Provides 5.0 VDC power for operating the device.
• Connects the device (up to five) to an Ethernet network.
• Simultaneously charges up to five TC75s or up to four TC75s and one 4-Slot Battery Charger using the
Battery Charger Adapter.
Figure 2-27 5-Slot Ethernet Cradle
CAUTION Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page
8-1.
