7 - 20 TC75 Integrator Guide
•Log path - Specifies the high level log path for storage of all kernal logs. This setting applies globally to all
kernal buffers.
• Kernal Log filename - Specifies the base log filename for this kernal buffer. The current file count is
appended to this name.
• Max Kernal log size - Specifies the maximum size, in kilobytes, of an individual log file.
• Kernal Log interval - Sets the interval, in milliseconds, on which to flush the log buffer to the file.
• Kernal Log file count - Specifies the number of log files to keep and rotate through. Each log file is subject
to the max log size option.
Configuration File
RxLogger configuration can be set using an XML file. The config.xml configuration file is located on the microSD
card in the RxLogger\config folder. Copy the file from the device to a host computer using a USB connection. Edit
the configuration file and the replace the .XML file on the device. There is no need to stop and restart the RxLogger
service since the file change is automatically detected.
Enabling Logging
To enable logging:
1. Touch .
2. Touch .
3. Touch Start.
4. Touch .
Disabling Logging
To disable logging:
1. Touch .
2. Touch .
3. Touch Stop.
4. Touch .
Extracting Log Files
1. Connect the device to a host computer using an USB connection.
2. Using a file explorer, navigate to the RxLogger folder.
3. Copy the file from the device to the host computer.
4. Disconnect the device from the host computer.
