A - 8 TC75 Integrator Guide
5-Slot Ethernet Cradle Technical Specifications
Humidity 0% to 95% non-condensing
Drop 76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature.
Electrostatic Discharge (ESD) +/- 20kV air
+/- 10kV contact
+/- 10kV indirect discharge
Table A-7 5-Slot Charge Only Cradle Technical Specifications
Item Description
Table A-8 5-Slot Ethernet Cradle Technical Specifications
Item Description
Dimensions Height: 21.7 cm (8.54 in.)
Width: 48.9 cm (19.25 in.)
Depth: 13.2 cm (5.20 in.)
Weight 2.25 kg (4.96 lbs)
Input Voltage 12 VDC
Power Consumption 65 watts
90 watts with 4-Slot Battery Charger installed.
Operating Temperature 0 °C to 50 °C (32 °F to 122 °F)
Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F)
Charging Temperature 0 °C to 40 °C (32 °F to 104 °F)
Humidity 5% to 95% non-condensing
Drop 76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature.
Electrostatic Discharge (ESD) +/- 20kV air
+/- 10kV contact
+/- 10kV indirect discharge
