Zebra TC75 Integrator Guide

Technical Specifications A - 7
2-Slot USB/Ethernet Cradle Technical Specifications
5-Slot Charge Only Cradle Technical Specifications
Table A-6 2-Slot USB/Ethernet Cradle Technical Specifications
Item Description
Dimensions Height: 20 cm (7.87 in.)
Width: 19.56 cm (7.70 in.)
Depth: 13.25 cm (5.22 in.)
Weight 870 g (30.7 oz.)
Input Voltage 12 VDC
Power Consumption 30 watts
Operating Temperature 0 °C to 50 °C (32 °F to 122 °F)
Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F)
Charging Temperature 0 °C to 40 °C (32 °F to 104 °F)
Humidity 5% to 95% non-condensing
Drop 76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature.
Electrostatic Discharge (ESD) +/- 20kV air
+/- 10kV contact
+/- 10kV indirect discharge
Table A-7 5-Slot Charge Only Cradle Technical Specifications
Item Description
Dimensions Height: 90.1 mm (3.5 in.)
Width: 449.6 mm (17.7 in.)
Depth: 120.3 mm (4.7 in.)
Weight 1.31 kg (2.89 lbs.)
Input Voltage 12 VDC
Power Consumption 65 watts
90 watts with 4–Slot Battery Charger installed.
Operating Temperature 0 °C to 50 °C (32 °F to 122 °F)
Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F)
Charging Temperature 0 °C to 40 °C (32 °F to 104 °F)

Zebra TC75 Specifications

General

Display Size	4.7 inches
Resolution	1280 x 720 pixels
Operating System	Android
Battery Capacity	4620 mAh
Cellular Connectivity	4G LTE
GPS	Yes
Humidity	5% to 95% non-condensing
Camera	8 MP rear camera
Wireless Connectivity	Wi-Fi 802.11 a/b/g/n
Ruggedness	MIL-STD-810G
Operating Temperature	-20° C to 50° C
Barcode Scanner	1D/2D imager
RAM	1 GB
Storage	8 GB
Expandable Storage	up to 32 GB microSD
Dimensions	6.3 x 3.3 x 1.1 inches
