Zebra TC75 Integrator Guide

A - 10 TC75 Integrator Guide
Magnetic Stripe Reader Technical Specifications
Humidity 5% to 95% non-condensing
Drop 76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature.
Electrostatic Discharge (ESD) +/- 20kV air
+/- 10kV contact
Table A-10 Charge Only Vehicle Cradle Technical Specifications
Item Description
Table A-11 Magnetic Stripe Reader Technical Specifications
Item Description
Dimensions Height: 5.18 mm (2.04 in.)
Width: 7.47 cm (2.94 in.)
Depth: 2.74 cm (1.08 in.)
Weight 37 g (1.3 oz.)
Input Voltage 5 VDC
Interface Serial with baud rate up to 19,200
Format ANSI, ISO, AAMVA, CA DMV
Certification PCI-DSS 2.0
Swipe Speed 5 to 50 in. (127 to 1270 mm) /sec, bi-directional
Decoders Generic, Raw Data
Mode Buffered, unbuffered
Track Reading Capabilities Tracks 1 and 3: 210 bpi Track 2: 75 and 210 bpi, autodetect
Operating Temperature -20 °C to 50 °C (xx °F to xx°F)
Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F)
Humidity 10% to 95% non-condensing
Drop 76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature.
Electrostatic Discharge (ESD) +/- 20kV air
+/- 10kV contact

Zebra TC75 Specifications

General

Display Size	4.7 inches
Resolution	1280 x 720 pixels
Operating System	Android
Battery Capacity	4620 mAh
Cellular Connectivity	4G LTE
GPS	Yes
Humidity	5% to 95% non-condensing
Camera	8 MP rear camera
Wireless Connectivity	Wi-Fi 802.11 a/b/g/n
Ruggedness	MIL-STD-810G
Operating Temperature	-20° C to 50° C
Barcode Scanner	1D/2D imager
RAM	1 GB
Storage	8 GB
Expandable Storage	up to 32 GB microSD
Dimensions	6.3 x 3.3 x 1.1 inches
