A - 6 TC75 Integrator Guide
2-Slot Charge Only Cradle Technical Specifications
4 TRIG_PTT Trigger or PTT input.
5 GND Power/signal ground.
6 USB-OTG_ID USB OTG ID pin.
7 TXD_EAR UART TXD, Headset ear.
8 USB_OTG_VBUS USB VBUS
9USB_OTG_DP USB DP
10 USB_OTG_DM USB DM
Table A-4 I/O Connector Pin-Outs
Pin Signal Description
Table A-5 2-Slot Charge Only Cradle Technical Specifications
Item Description
Dimensions Height: 10.6 cm (4.17 in.)
Width: 19.56 cm (7.70 in.)
Depth: 13.25 cm (5.22 in.)
Weight 748 g (26.4 oz.)
Input Voltage 12 VDC
Power Consumption 30 watts
Operating Temperature 0 °C to 50 °C (32 °F to 122 °F)
Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F)
Charging Temperature 0 °C to 40 °C (32 °F to 104 °F)
Humidity 5% to 95% non-condensing
Drop 76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature.
Electrostatic Discharge (ESD) +/- 20kV air
+/- 10 kV contact
+/- 10 kV indirect discharge
