Zebra TC75 Integrator Guide

2 - 20 TC75 Integrator Guide
Figure 2-19 Remove Cup
4. Carefully lift the cup up to expose the cup power cable.
5. Disconnect the cup power cable.
Figure 2-20 Disconnect Cup Power Cable
6. Connect the Battery Adapter power cable to the connector on the cradle.
NOTE Place power cable into adapter to avoid pinching cable.

Zebra TC75 Specifications

General

Display Size	4.7 inches
Resolution	1280 x 720 pixels
Operating System	Android
Battery Capacity	4620 mAh
Cellular Connectivity	4G LTE
GPS	Yes
Humidity	5% to 95% non-condensing
Camera	8 MP rear camera
Wireless Connectivity	Wi-Fi 802.11 a/b/g/n
Ruggedness	MIL-STD-810G
Operating Temperature	-20° C to 50° C
Barcode Scanner	1D/2D imager
RAM	1 GB
Storage	8 GB
Expandable Storage	up to 32 GB microSD
Dimensions	6.3 x 3.3 x 1.1 inches
