Product Manual - ZMORPH FAB back to table of content
>>
69
Set the printing temperature
to the PLA material., Nozzle
To do that tap the gaps and
type the temperature on the
screen.
Wait for the extruder to heat
up. When done tap ‘NEXT’.
Use the arrow buttons on the
screen to feed the material on
the extruder until it start to pour
out from the nozzle. (it might
take a couple times), after that
press the ‘NEXT’ button.
printing pattern.
NOTE: by pressing the
‘SKIP’ button the user is
approving the automatic
calibration without visual
validation. After that the
calibration process ends.
Look at the printed lines and
select the best one on the
screen. A correct line is the
one that sticks to the table
after gently touching it with
Apply your choice. Zmorph Fab calibration is
complete.
NEXTBACK
CURRENTTARGET
NOZZLE
BED
LOAD FILAMENT
NEXTBACK
NONE, REPEAT PRINTING
1 2 3 4 5
NEXT
Choose the best printed line
(numeration from le to right)
NEXTBACK
TARGET
NOZZLE
BED
CURRENT
In the last calibration step the machine
will print five lines as a final touch
SKIP
START
CALIBRATION
DONE
3D printing workow
being the result of the automatic calibration process.
NOTE
