Phantom power settings
104
Phantom power settings
Set the PHANTOM switch to ON to supply phantom power to INPUTS 3~8.
/ÊVÃiÀÛiÊL>ÌÌiÀiÃ]ÊÞÕÊV>ÊÌÕÀÊÌÊvvÊvÀÊ«ÕÌÊ«>ÀÃÊÎÉ{Ê>`ÊÇÉnÊ>`ÊÀi`ÕViÊÌiÊÛÌ>}iÊÌÊÓ{Ê6° Ê
Setting phantom power
TOOL>SYSTEM>PHANTOM
1
Press
Press
Select SYSTEM.
2
Change menu
4
Select VOLTAGE and set the value.
3
Select PHANTOM.
Press
Change menu
Change menu
Change setting
Change setting
5
Select 3/4ch or 7/8ch and set
it to On or Off.
Change menu
NOTE
UÊ /iÊ«>ÌÊ«ÜiÀÊvÀÊ«ÕÌÃÊxÊ>`ÊÈÊV>ÌÊLiÊ
turned off separately. They will be supplied with
phantom power unless the PHANTOM switch is set
to OFF.
UÊÊ "/ÊÃÕ««ÞÊ«>ÌÊ«ÜiÀÊÌÊVÀ«iÃÊ
>`ÊÃÌÀÕiÌÃÊ Ì>ÌÊ `Ê ÌÊ ii`Ê Ì°Ê }Ê ÃÊ
could cause damage. Check the instructions
for the microphone that you are using before
supplying phantom power.
System
