Zoom R24 User Manual

Panel layout and functions
9
Panel layout and functions
-ÊV>À`ÊÃÌÊ
USB HOST
port
USB DEVICE
port
ë>ÞÊ
TEMPO
key
ÕÌÊV
Level meters
(1/9/17
~
8/16/24
,
MASTER)
&ADER SECTION
Transport section
Control section
Display section
Rear panel
Right side panel
Bottom panel (not shown)
>ÌÌiÀÞÊV«>ÀÌiÌ
Soft keys
Input section
TEMPO
indicator

Zoom R24 Specifications

General

Sample rate	96 kHz
Channels quantity	10 channels
Digital sound processing	24 bit
USB 2.0 ports quantity	1
DJ mixer	-
Product color	Silver

Weight and Dimensions

Depth	237.1 mm
Width	376 mm
Height	52.2 mm
Weight	1300 g
