Chapter 1 Introduction
EMG2306-R10A User’s Guide
14
1.6 The WPS Button
Your EMG2306-R10A supports WiFi Protected Setup (WPS), which is an easy way to set up a secure
wireless network. WPS is an industry standard specification, defined by the WiFi Alliance.
WPS allows you to quickly set up a wireless network with strong security, without having to
configure security settings manually. Each WPS connection works between two devices. Both
devices must support WPS (check each device’s documentation to make sure).
Depending on the devices you have, you can either press a button (on the device itself, or in its
configuration utility) or enter a PIN (a unique Personal Identification Number that allows one device
to authenticate the other) in each of the two devices. When WPS is activated on a device, it has two
minutes to find another device that also has WPS activated. Then, the two devices connect and set
up a secure network by themselves.
For more information on using WPS, see Section 7.2 on page 40.
LAN 1-4 Green On The EMG2306-R10A’s LAN connection is ready.
Blinking The EMG2306-R10A is sending/receiving data through the LAN
with a 10/100Mbps transmission rate.
Off The LAN connection is not ready, or has failed.
WLAN
Green On The EMG2306-R10A is ready, but is not sending/receiving data
through the wireless LAN.
Blinking The EMG2306-R10A is sending/receiving data through the
wireless LAN.
Off The wireless LAN is not ready or has failed.
WPS
Green On The WPS status is configured.
Blinking The EMG2306-R10A is negotiating a WPS connection with a
wireless client.
Off The WPS function is disabled on the EMG2306-R10A.
(INTERNET)
Green On Internet (WAN) connection is up (e.g. PPPeE/DHCP Client).
Blinking Internet connection established.
Off Internet connection is down.
Table 1 Front panel LEDs and WPS button (continued)
LED COLOR STATUS DESCRIPTION
To Next Page
