Chapter 7 Tutorials
EMG2306-R10A User’s Guide
42
3 Click Start buttons (or button next to the PIN field) on both the wireless client utility screen and the
EMG2306-R10A’s WPS Station screen within two minutes.
The EMG2306-R10A authenticates the wireless client and sends the proper configuration settings to
the wireless client. This may take up to two minutes. Then the wireless client is able to
communicate with the EMG2306-R10A securely.
The following figure shows you the example to set up wireless network and security on EMG2306-
R10A and wireless client (ex. NWD210N in this example) by using PIN method.
Figure 20 Example WPS Process: PIN Method
7.3 Configure Wireless Security without WPS
This example shows you how to configure wireless security settings with the following parameters
on your EMG2306-R10A.
Follow the steps below to configure the wireless settings on your EMG2306-R10A.
WITHIN 2 MINUTES
Wireless Client
Access Point
SSID SSID_Example
Channel 6
Security WPA-PSK
(Pre-Shared Key: ThisismyWPA-PSKpre-sharedkey)
To Next Page
