Chapter 9 Wireless LAN
EMG2306-R10A User’s Guide
87
certain times. To open this screen, click Configuration > Network > Wireless LAN >
Scheduling.
Figure 43 Configuration > Network > Wireless LAN > Scheduling
The following table describes the labels in this screen.
9.13 WDS
A Wireless Distribution System is a wireless connection between two or more APs. Use this screen
to set the operating mode of your EMG2306-R10A to AP + Bridge or Bridge Only and establish
wireless links with other APs. You need to know the MAC address of the peer device, which also
must be in bridge mode.
Table 33 Configuration > Network > Wireless LAN > Scheduling
LABEL DESCRIPTION
Enable Wireless LAN
Scheduling
Select this to enable Wireless LAN scheduling.
Scheduling
WLAN Status Select On or Off to specify whether the Wireless LAN is turned on or off. This field
works in conjunction with the Day and For the following times fields.
Day Select Everyday or the specific days to turn the Wireless LAN on or off. If you select
Everyday you can not select any specific days. This field works in conjunction with the
For the following times field.
At the following
times (24-Hour
Format)
Select a begin time using the first set of hour and minute (min) drop down boxes and
select an end time using the second set of hour and minute (min) drop down boxes. If
you have chosen On earlier for the WLAN Status the Wireless LAN will turn on between
the two times you enter in these fields. If you have chosen Off earlier for the WLAN
Status the Wireless LAN will turn off between the two times you enter in these fields.
Apply Click Apply to save your changes back to the EMG2306-R10A.
Cancel Click Cancel to exit this screen without saving.
