Chapter 7 Tutorials
EMG2306-R10A User’s Guide
47
For example, you may set up three wireless networks (A, B and C) in your office. A is for workers,
B is for guests and C is specific to a VoIP device in the meeting room.
7.4.1 Configuring Security Settings of Multiple SSIDs
The EMG2306-R10A is in router mode by default.
This example shows you how to configure the SSIDs with the following parameters on your
EMG2306-R10A (in router mode).
1 Connect your computer to the LAN port of the EMG2306-R10A using an Ethernet cable.
2 The default IP address of the EMG2306-R10A in router mode is “192.168.1.1”. In this case, your
computer must have an IP address in the range between “192.168.1.2” and “192.168.1.254”.
3 Click Start > Run on your computer in Windows. Type “cmd” in the dialog box. Enter “ipconfig” to
show your computer’s IP address. If your computer’s IP address is not in the correct range then see
Appendix C on page 176 for information on changing your computer’s IP address.
4 After you’ve set your computer’s IP address, open a web browser such as Internet Explorer and
type “http://192.168.1.1” as the web address in your web browser.
5 Enter “1234” (default) as the password and click Login.
A
B
C
SSID_Guest
SSID_Worker
SSID_VoIP
SSID SECURITY TYPE KEY MAC FILTERING
SSID_Worker WPA2-PSK
WPA Compatible
DoNotStealMyWirelessNetwork Disable
SSID_VoIP WPA-PSK VoIPOnly12345678 Allow
00:A0:C5:01:23:45
SSID_Guest WPA-PSK keyexample123 Disable
