Chapter 9 Wireless LAN
EMG2306-R10A User’s Guide
80
9.6 More AP
This screen allows you to enable and configure multiple wireless networks on the EMG2306-R10A.
Select Configuration > Network > Wireless LAN > More AP. The screen appears as shown.
Figure 36 Wireless LAN > More AP
The following table describes the labels in this screen.
Table 26 Wireless LAN > More AP
LABEL DESCRIPTION
# This is the index number of each SSID profile.
Status Shows the status of the SSID.
SSID The SSID (Service Set IDentifier) identifies the Service Set with which a wireless device
is associated.
This field displays the name of the wireless profile on the network. When a wireless
client scans for an AP to associate with, this is the name that is broadcast and seen in
the wireless client utility.
Security This field indicates the security mode of the SSID profile.
Edit Click the Edit icon to configure SSID profile.
