5.2 Router Mode Status Screen
Click to open the status screen.
Figure 11 Status Screen: Router Mode
The following table describes the icons shown in the Status screen.
Table 8 Status Screen Icon Key: Router Mode
ICON DESCRIPTION
Logout Click this at any time to exit the Web Configurator.
Click this icon to view copyright and a link for related product information.
Select a number of seconds or None from the drop-down list box to refresh all screen statistics
automatically at the end of every time interval or to not refresh the screen statistics.
Click this button to refresh the status screen statistics.
Click this icon to see the Status page. The information in this screen depends on the device
mode you select.
