Chapter 5 Router Mode
EMG2306-R10A User’s Guide
27
The following table describes the labels shown in the Status screen.
Click this icon to see the Monitor navigation menu.
Click this icon to see the Configuration navigation menu.
Click this icon to see the Maintenance navigation menu.
Table 8 Status Screen Icon Key: Router Mode (continued)
ICON DESCRIPTION
Table 9 Status Screen: Router Mode
LABEL DESCRIPTION
Device Information
Host Name This is the device’s host name.
Model Number This is the device’s model number.
Firmware Version This is the firmware version.
Sys OP Mode This shows the device mode to which the EMG2306-R10A is set.
WAN Information
- MAC Address This shows the WAN Ethernet adapter MAC Address of your device.
- IP Address This shows the WAN port’s IP address.
- IP Subnet Mask This shows the WAN port’s subnet mask.
- Default Gateway This shows the default gateway address.
LAN Information
- MAC Address This shows the LAN Ethernet adapter MAC Address of your device.
- IP Address This shows the LAN port’s IP address.
- IP Subnet Mask This shows the LAN port’s subnet mask.
- DHCP This shows the LAN port’s DHCP role - Server or Disable.
WLAN Information
- WLAN OP Mode This shows the device mode to which the EMG2306-R10A’s wireless LAN is set.
- MAC Address This shows the wireless adapter MAC Address of your device.
- SSID This shows a descriptive name used to identify the EMG2306-R10A in the wireless LAN.
- Channel This shows the channel number which you select manually.
- Security This shows the level of wireless security the EMG2306-R10A is using.
Firewall This shows the firewall enabled or not.
System Status
Item This column shows the type of data the EMG2306-R10A is recording.
Data This column shows the actual data recorded by the EMG2306-R10A.
System Up Time This is the total time the EMG2306-R10A has been on.
Current Date/Time This field displays your EMG2306-R10A’s present date and time.
System Resource
- CPU Usage This displays what percentage of the EMG2306-R10A’s processing ability is currently used.
When this percentage is close to 100%, the EMG2306-R10A is running at full load, and the
throughput is not going to improve anymore. If you want some applications to have more
throughput, you should turn off other applications (for example, using bandwidth
management.)
