4-4
Pioneer Gold 3.00 Controller Technical Guide
SCREENS
Setpoints
Dehumidication Setpoints
• Dehumidification Enable: If Space RH is above
• Dehumidication Lockout: If the Space Temp is below
• Supply Air Reheat Setpoint: In the Modulating Reheat
mode, the controller will try to maintain this setpoint.
Economizer Setpoints
• Economizer Cooling Enable: If the Entering Water
Temperature is below this value, the Economizer can be
• Economizer Heating Enable: If the Entering Water
Temperature is Above this value, the Economizer can be
• Water Econ Cooling Failure Time and
Water Econ Heating Failure Time
If the Waterside Economizer is enabled for cooling
or heating, the failure time is the time period before
it switches to Compressor Cool or Heat. Setting the
value to 255 will disable the timer so the Waterside
Compressor Setpoints
• Minimum On Time: Compressor must run for this amount
Range: 120-255 seconds
• Minimum Off Time: Compressor must remain for
this amount of time before it can turn on.
• Interstage On Delay: If Stage 1 is energized, the
controller must wait for this amount of time before
Range: 30-255 seconds
• Interstage O Delay: If Stage 2 is energized, the
controller must wait for this amount of time before
Range: 30-255 seconds
Dehum Enable
Dehum Lockout
55ºF
50%
Supply Air Reheat
70ºF
Dehumidification Setpoints
MAIN MENU
MAIN MENU
Setpoints
Setpoints
Econ Cool Enable
45ºF
Econ Heat Enable
85ºF
Economizer Setpoints
MAIN MENU
MAIN MENU
Setpoints
Setpoints
Min Off Time
120 s
Interstage On Delay
60 s
Compressor Setpoints
MAIN MENU
MAIN MENU
Setpoints
Setpoints
Min On time
180 s
Interstage Off Delay
60 s
Figure 4-8: Setpoints - Dehumidication
Figure 4-9: Setpoints - Economizer
Figure 4-10: Setpoints - Compressor
