4-6
Pioneer Gold 3.00 Controller Technical Guide
SCREENS
Viewing Alarms
Alarm Status
From the Main Menu Screen, press the <Alarms> icon. The
Alarms 1 Screen will appear. See Figures 4-14, this page. There
are two Alarms Screens. Press the <Next> button to access the
next screen. Press the <Back> button to access the previous
screen. Press the <EXIT> button to return to the Main Screen.
The status for each alarm should be Ready or Normal. If there
is an alarm, the word Alarm will appear in red. The abbreviation
L.O. in red stands for “Locked Out”. This means that there is
currently one or more alarms active, and any item that shows
by the particular alarm. Continue scrolling through the Alarms
pages until you see the item that shows “Alarm” to identify
which item is in an alarm state that is causing associated items
to be Locked Out.
Econ Failed
Condensate Overflo
Low Voltage
High Voltage Normal
Normal
Normal
Normal
Water Leaving Temp
Water Entering Temp
Evaporator Temp
High Pressure Alarm
Normal
Normal
Alarm
General Alarms 1
NEXT
NEXT
EXIT
EXIT
Emergency Shutdwn
Auxiliary Input
Low Suction
DI2 Comp Interlock Normal
Alarm
Normal
Normal
DI1 Comp Interlock
Space Sensor
Liquid Line Temp
CO2 Override Normal
Normal
Normal
Normal
General Alarms 2
EXIT
EXIT
BACK
BACK
Figure 4-14: General Alarms Screens
