AAON ASM02780 User Manual

1-35
Pioneer Gold 3.00 Controller Technical Guide
Figure 1-15: BACnet
®
Connection to MS/TP Network or IP BAS Network (ASM02323 Only)
LM2904
M2904
B
L
T
B
t
.
L
A
B
O
R
T
I
E
S
A
R
O
.
T
E
S
T
R
I
G
N
A
C
n
e
2019WXX
Ethernet Cable
(Not Included)
Connect to BACnet
®
BAS Network
IP Connection To
BACnet
®
Network
MS/TP Connection To
BACnet
®
Network
Programming Note:
Use the Network Menu in the Touchscreen
LCD Display to program the BACnet
®
MS/TP
setting.
Wiring Notes:
1. All wiring to be in accordance with local and
national electrical codes and specifications.
2. All communication wiring to be 18-gauge
minimum, two-conductor, twisted-pair with
shield. Use Belden #82760 or equivalent.
Typical terminal blocks. All
wiring to be S (G) to S (G),
A- to A-, and B+ to B+
BACnet
®
MS/TP AND IP PARAMETERS
BACnet
®
Connection to MS/TP or IP BAS Network
