1-36
Pioneer Gold 3.00 Controller Technical Guide
BACnet
®
MS/TP and IP Analog Inputs
BACnet
®
Point #
BACnet
®
Point Name
BACnet
®
Description
Unit
AI:1 Entering Water Temp Temperature of the loop water entering the water coil Fahrenheit
AI:2 Liquid Line Temp Temperature of the refrigerant liquid line Fahrenheit
AI:3 Entering Hot Water
Temp
Temperature of the water entering the hot water coil Fahrenheit
AI:4 Temperature of the air coil Fahrenheit
AI:5 Temperature of the discharge air Fahrenheit
AI:6 Space Temperature Temperature reading from the space sensor Fahrenheit
AI:7 Space Relative
Humidity
RH reading from the space sensor Relative Humidity
AI:8
level reading from the space sensor PPM
AI:9 Firmware Version No Units
AI:10 Discharge Pressure Pressure reading from the discharge pressure transducer PSI
AI:11 Suction Pressure Pressure reading from the suction pressure transducer PSI
AI:12
Percentage
Percentage output to an analog water valve or pump Percent
AI:13 Hot Water Valve
Percentage
Percentage output to the hot water heat coil valve Percent
AI:14 Supply Fan
Percentage
Percentage output for a variable speed supply fan Percent
AI:15 Damper Override
Percentage
Percent
AI:16
Percentage
Percent
AI:17 Leaving Water Temp Temperature of the loop water leaving the water coil Fahrenheit
AI:18
Occupied cooling setpoint with the user adjustment from the touchscreen
sensor added
Fahrenheit
AI:19 Occupied Heating
Occupied heating setpoint with the user adjustment from the touchscreen
sensor added
Fahrenheit
AI:20 Reheat Valve
Percentage
Position of modulating hot gas reheat valve Percent
Table 1-15: BACnet
®
MS/TP and IP Parameter Analog Inputs
BACnet
®
MS/TP AND IP PARAMETERS
BACnet
®
MS/TP and IP Analog Inputs
