Subsystem Status Displays Section 6 Status Displays
124 3BUR002418-600 A
the status of Control Modules 1 through 12. ADVANT STATION icons contain two
status boxes that indicate the status of the Real Time Accelerator Board. AC410 and
AC460 icons contain two status boxes that indicate the status of the DCN interface
submodules, and AC460 icons have up to three additional status boxes that indicate
the status of controllers.
State Definitions
The system state executive indicates the current status of a device or subdevice
through the following state definitions:
Subsystem Status Displays
The Subsystem Status Displays provide information on the node’s condition.
Table 6. State Definitions
STATE COLOR DEFINITION
Blank No Control Module configured.
ACTIVE Green Device or subdevice is running.
AVAILABLE Cyan Program has downloaded and database is
downloading.
DOWN Red Fatal failure (that is, communications has failed)
or device/subdevice may be down.
HOLD Cyan Hardware error (that is, digital input, analog
input) or configured hold to allow other Control
Module with softwired data to become active.
IMPAIRED Cyan Backup Control Module running but is not yet
rebooted.
READY Yellow Database download is complete; normal state
for backup controller.
UNKNOWN Red State is not known.
