Sequence Detail Display Section 4 TCL Displays
84 3BUR002418-600 A
Sequence Detail Display
The Sequence Detail Display, Figure 34, supports runtime monitoring and
manipulation of an individual sequence. Most of the runtime changes made to a
sequence are done from this display. The changes you can make include:
• Step manipulation (up to 255 steps supported).
• Sequence state, mode, or status.
Figure 34. Sequence Detail Page
A limit of 255 steps can be displayed. Additional steps are indicated by the text:
“*TEXT NOT AVAILABLE*”. These steps can be expanded on the SFC display
to get their data.
