Appendix A Runtime Templates Sum of 4 Inputs FCM
3BUR002418-600 A 257
• Exponentiation
• Multiplication
• Absolute Value
Sum of 4 Inputs FCM
The Sum of 4 Inputs FCM finds the sum of up to 4 input signals, each with an
optional scaling constant.
Constant 1 through Constant 4 Fields
These fields specify the values of the constants. Valid entry is any number
Polynomial FCM
The Polynomial FCM allows for polynomial curve fitting linearization for up to a
third order fit.
Constant 1 through Constant 4 Fields
These fields specify the values of the constants. Valid entry is any number
Average FCM
The Average FCM finds the arithmetic average of up to 4 inputs. You can use
constant factors to scale the inputs.
Constant 1 through Constant 4 Fields
These fields specify the values of the constants. Valid entry is any number
MINIMUM # INPUTS Field
This field specifies the minimum number of inputs that must have a data quality of
GOOD for the algorithm to calculate. Valid entries are: 2, 3, 4 or ALL INPUTS.
