PROFIBUS Module/Channel Status Area
The channel status window section shows specific information about each channel
of the module. A scroll bar is used to view other channels of the device. For each
channel, several columns of information are displayed as described below.
Startup
All output values are set to zero (0) on PROFIBUS startup.
Channel The input (IN) or output (OUT) and channel number of the device.
The text color for each channel is based upon the data quality:
Dark Green = data quality is good.
Red = data quality is bad
CCF Tag
and
TLL Tag
The TAG is the name of the CCF loop or the TLL device that uses
the channel. If no loop or device is assigned to the channel then
the field is blank.
Select the CCF or TLL Tag target area to get the appropriate MOD
Faceplate.
Select the context menu for CCF or TLL tag to navigate to the
Loop FCM or Loop Detail display.
Value The actual value of the input from the process or the output value
sent to the process.
For an output field, you can change the value of an output channel
by selecting it and entering a value.
Diagnostics Diagnostics from the PROFIBUS device. See the vendor manual
for detailed information.
