S800 Device Display Section 7 I/O Displays
158 3BUR002418-600 A
The next section gives information about the I/O module selected.
The channel window section shows specific information about each channel of the
module. A scroll bar is used to view other channels of the device. For each channel,
several columns of information are displayed as described below.
Templet The device name created during database configuration is given in
this field.
Label This field shows the label given this I/O module.
Revision Gives the revision level of the module if available.
Config Type This field shows the I/O module type that was configured for this
device number.
Actual Type This field shows the actual I/O module type that is inserted in this
device number location.
Dev State This field shows the status of the I/O module. ACTIVE indicates
the I/O module is OK. FAILED means the I/O module has stopped.
MISSING means there is not an I/O module installed.
Channel The input (IN) or output (OUT) and channel number of the device.
The text color for each channel is based upon the reporting of
faults and the data quality:
Dark Green = Report faults is yes and data quality is good.
Red = Report faults is yes and data quality is bad
Light Green = Report faults is no, data quality is forced to
‘good’
CCF Tag
and
TLL Tag
The TAG is the name of the CCF loop or the TLL device that uses
the channel. If no loop or device is assigned to the channel then
the field is blank.
Select the CCF or TLL Tag target area to get the appropriate MOD
Faceplate. If a tag is configured for warmstart and is warm started,
it is shown with a white background.
