Appendix A Runtime Templates AO810, AO890
3BUR002418-600 A 297
The default value is 1024.
OSP VALUE 01 through 08
Enter the channel value in counts to output after an OSP TIMEOUT. If the OSP
HOLD has been selected as the OSP value then this field entry is ignored.
The valid values are:
0 to 28480.
Where 0 = 0 mA and 28480 = 20 mA (Counts per mA = 1424)
The default is 0.
POSITION
Enter a number from 1 to 12 representing the position of the I/O module relative to
the FCI. The I/O module directly next to the FCI is number 1.
Default value is 1.
REPORT FAULTS 01 through 08
If channel faults are to be reported, enter a YES; if not enter a NO.
The default value is YES.
RESERVED OPTIONS
Used to select I/O module type:
Enter:
0 (zero) for the AO810 Module
274333696 for the AO890 Module
The default value is 0 (zero).
If positions are to be used for spare MTUs, the spares must be in place so the rest
of the I/O modules are numbered correctly. The spare MTU will use a position
number when it is on the ModuleBus.
