DI810 Appendix A Runtime Templates
302 3BUR002418-600 A
LABEL
Enter a characteristic name to identify the DI810 or DI890 Module of the station.
The name may contain up to 20 characters.
MONITOR POWER
To monitor process power source enter a YES; if not needed enter a NO.
DI890 with any channel supervision requires that MONITOR POWER = YES.
Default Value is NO.
POSITION
Enter a number from 1 to 12 representing the position of the I/O module relative to
the FCI. The I/O module directly next to the FCI is number 1.
Default value is 1.
REPORT FAULTS 01 through 16
If channel faults are to be reported, enter a YES;
if not enter a NO.
The default value is YES.
RESERVED OPTIONS
Used to select I/O module type:
Enter:
0 (zero) for the DI810 Module.
542769152 for the DI890 Module (decimal value for all channels without
supervision) see table below where a “1” sets supervision for channels 8 - 1.
For the DI890 module, enter a description that includes the module type for
future reference to help alleviate confusion with an DI890 being used in the
DI810 templet.
